operating table /electric hydraulic operating table
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Overview
Essential details
| Type: | Operating Table, Operating Table | Brand Name: | shanghai feiman |
| Model Number: | AT600A | Place of Origin: | Shanghai, China |
| Instrument classification: | Class II | Power Source: | electric hydraulic |
| Warranty: | 1 Year | After-sale Service: | Online technical support |
| Material: | 304Stainless steel | Product name: | Hydraulic lift column |
| Lifting Size: | 540mm-1040mm | Left and right angle: | ±20° |
| Front and back tilt: | ±30° | translation: | 300mm |
Supply Ability
| Supply Ability | 200 Piece/Pieces per Month |
Packaging & delivery
| Packaging Details | Export wooden case | Port | shanghai |
Video Description
Product Detail
Electric hydraulic Operating Table, can be installed on any brand operating table, lift and lift 680mm-1040mm, tilt angle of 30 degrees, around 20 degrees, horizontal moving 370mm, with two brake oil pressure cylinder, The electric hydraulic system is divided into two systems, the oil section and the circuit part. The oil circuit includes the oil pump, the oil pipe, the electromagnetic valve group and the oil pressure cylinder; the circuit part contains the most basic functional configuration of the remote control, the power supply, the main board and so on.also according to customer needs to customize other styles and so
parameter
| Model | AT600A |
| Length | 2070mm |
| width | 520mm |
| Front and rear tilt | ±30° |
| Left and right inclination | ±20° |
| Back angle | +80°- -40° |
| Vertical translation | 300mm |
| Foot angle | +30°--90° |
| Horizontal angle of legs | 180° |
| Lifting range | 520mm-1040mm |
